Lithonia Lighting Quantum LED Emergency Exit Sign, Thermoplastic Exit Only Sign with Stencil-Faced White Housing and Green Letters (LQM S W 3 G 120/277 M6)
Product details
| Management number | 209024133 | Release Date | 2026/03/29 | List Price | $20.00 | Model Number | 209024133 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product Description Engineering-grade thermoplastic housing with stencil faced white housing and green letter, is impact-resistant, scratch resistant, and corrosion-proof. UL94V-0 flame rating. UV-stable resin resists discoloration from natural and man-made light sources. Rugged Uni-body housing snaps together with no additional mechanical fasteners. Faceplate and back cover are interchangeable on housing. Positive snap-fit tabs hold faceplate securely, yet easily removable for lamp compartment access. Single face with extra faceplate and color panel. Ideal for applications requiring attractive, quick-installation exit signs and low energy consumption. From the Manufacturer Engineering-grade thermoplastic housing with stencil faced white housing and green letter, is impact-resistant, scratch resistant, and corrosion-proof.
- VERSATILE EXIT-ONLY SIGN: The Lithonia Lighting Quantum LED Exit Sign is ideal for applications requiring attractive, quick-installation exit signs and low energy use; It includes an additional faceplate to convert from single-sided to double-sided exit
- BRIGHT GREEN LED EXIT SIGN: Letters are 6" high with 3/4" stroke, with 100 ft. viewing distance rating; The exit sign provides uniform graphics illumination without shadows or hot spots; Directional chevron inserts are easily removed and reinserted
- ELECTRICAL DETAILS: Constant-current series charger minimizes energy consumption and provides low operating cost; The typical life of the exit LED lamp is 5 years; This version is AC-only with no battery backup
- EASY INSTALLATION: Unibody housing snaps together easily; Faceplate and back cover are interchangeable; The LED emergency exit sign includes a mounting canopy for top or end mount; Back mount standard for single face only
- SPECIFICATIONS: UL Damp Location Listed, Title20, Meets UL924, NFPA 101, NEC & OSHA illumination standards, meets all applicable FCC Title 47, Part 15, Subpart B requirements; Dual voltage 120/277V; Dimensions 11.75" x 7.63" x 2"; 5-year limited warranty
| UPC | 784231011584 |
|---|---|
| Size | 11.75" | Sign Only |
| Color | Green |
| Material | Thermoplastic |
| Brand Name | Lithonia Lighting |
| Light Type | LED |
| Unit Count | 1.0 Count |
| Item Weight | 1 Kilograms |
| Orientation | Portrait |
| Part Number | LQM S W 3 G 120/277 M6 |
| Manufacturer | Lithonia Lighting |
| Model Number | LQM S W 3 G 120/277 M6 |
| Mounting Type | Wall Mount |
| Number of Pieces | 1 |
| Pre Printed Text | exit |
| Included Components | Product & Instructions Guide |
| Warranty Description | All products purchased have a 30-day replacement parts policy to ensure a fully working item. All products are covered under a 1-year warranty when purchased on amazon. The warranty period begins on the day the product is originally shipped. The warranty covers all of the items and conditions identified in the original manufacturers warranty. Some of the items specifically not covered by the warranty are loss and theft, water damage, customer abuse, and finish detoriation due to uv or coastal exposure. |
| Item Dimensions L x W | 11.75"L x 7.62"W |
| Recommended Uses For Product | Exit |
| Global Trade Identification Number | 30784231011585 |
